Smart Switch Software User Manual GS748T
4-24 Configuring the Switch
v1.0, October 2007
Viewing Packet Statistics
The Port Statistics screen shows reports of packet traffic and packet errors formatted as follows:
• Port Selection: The port number on the switch—selected from the Port pull-down menu.
• Statistics: Detailed Tx and Rx statistical information, by port.
• Summary Statistics: All ports Tx and Rx statistics summarized. Presents the information
from each port’s internal counters.
To view statistics for a single port:
1. From the Port pull-down menu, select the port number.
2. Click Apply.
To retrieve summary statistics.
1. Click Refresh to retrieve the current count from the device and update the tables.
2. Click Clear Counters to reset all counters to zero.
Figure 4-23
