NETGEAR GS748TNA

Smart Switch Software User Manual GS748T
Network Cabling C-7
v1.0, October 2007
Conclusion
For optimum performance of your 1000BASE-T product, it is important to fully qualify your cable
installation and ensure that it meets or exceeds ANSI/EIA/TIA-568-A:1995 or ISO/IEC
11801:1995 Category 5 specifications. Install Category 5e cable where possible, including patch
panel cables. Minimize transition points, jacket removal, and untwisted lengths. Cable bundles
must be properly installed to meet the requirements in ANSI/EIA/TIA-568A-3.
Table C-3. 100/1000 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments
Pin Channel Description
1
2
A Rx/Tx Data +
Rx/Tx Data
3
6
B Rx/Tx Data +
Rx/Tx Data
4
5
C Rx/Tx Data +
Rx/Tx Data
7
8
D Rx/Tx Data +
Rx/Tx Data
