Introduction
6
NETGEAR Managed Stackable Switch M5300 Series
Figure 2. M5300 series front panels
Table 1. LED descriptions for M5300 Series switches
LED Description
Stack ID Stack ID is the stack member ID (1–8) that the software assigns to the switch. The
decimal point to the right of the ID number lights up when the switch acts as a master unit
in an M5300 Series stack.
Power • Solid green: The power module is present, is supplying power to the switch, and is
working normally.
• Blinking green: The power module has failed, and system power is being supplied
from the RPS, or the RPS4000 is in EPS mode.
• Solid yellow: The system is in the boot-up stage.
• Blinking yellow: System boot-up has failed or there is some other failure.
• Off: Power is disconnected.
Fan • Solid green: The fan is operating normally.
• Solid yellow: The fan has failed.
• Off: No fan is detected.
10GBT ports
(1 LED per port)
SPD/ Link/ACT LED:
• Off: No SFP module link is established on the port.
• Solid Green – A valid 10 Gbps link is established on the port.
• Blinking Green –10 Gbps packet transmission or reception is occurring on the port.
• Solid Yellow –A valid 100 Mbps or 1 Gbps link is established on the port.
• Blinking Yellow – 100 Mbps or 1 Gbps packet transmission or reception is occurring
on the port.
Note: If a combo port media changes to SFP+, the copper port
LED turns off.
SFP+ ports
(1 LED per port)
• Off: No SFP/SFP+ module link is established on the port.
• Solid green: A valid 10 Gbps SFP+ module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 10 Gbps.
• Solid yellow: A valid 1 Gbps SFP module link is established on the port.
• Blinking yellow: Packet transmission or reception is occurring on the port at 1 Gbps.
Note: If a combo port media changes to copper, the SFP/SFP+
port LED turns off.
