NETGEAR R7500 User Manual

Table 1. LED and button descriptions
DescriptionLED
Power
•
Solid amber.The router is starting.
•
Blinking amber.The firmware is upgrading, or the Reset button was
pressed.
•
Solid white.The router is ready.
•
Blinking white.The firmware is corrupted.
•
Off. Power is not supplied to the router.
Internet
•
Solid white.The Internet connection is ready.
•
Solid amber.The router detected an Ethernet cable connection to the
modem.
•
Off. No Ethernet cable is connected between the router and the modem.
2.4 GHz WiFi
•
Solid white.The 2.4 GHz WiFi radio is operating.
•
Blinking.The router is sending or receiving WiFi traffic.
•
Off.The 2.4 GHz WiFi radio is off.
5 GHz WiFi
•
Solid white.The 5 GHz WiFi radio is operating.
•
Blinking.The router is sending or receiving WiFi traffic.
•
Off.The 5 GHz WiFi radio is off.
USB 3.0 port 1 and USB 3.0
port 2
•
Solid white. A USB device is connected and is ready.
•
Blinking. A USB device is plugged in and is trying to connect.
•
Off. No USB device is connected, or someone clicked the Safely Remove
Hardware button and it is now safe to remove the attached USB device.
eSATA
•
Solid white. An eSATA device is connected and is ready.
•
Blinking. An eSATA device is plugged in and is trying to connect.
•
Off. No eSATA device is connected.
The LED color indicates the speed: white for Gigabit Ethernet connections and
amber for 100 Mbps or 10 Mbps Ethernet connections.
Ethernet ports 1–4
Hardware Setup
10

NETGEAR R7500 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC2350 (600 + 1733 Mbps)
Number of Ethernet Ports	5
Antenna	4 external antennas
Beamforming+	Yes
Dynamic QoS	Yes
MU-MIMO	Yes
VPN Support	Yes
WiFi Band	Dual Band 2.4GHz and 5GHz
Ethernet Ports Speed	Gigabit (10/100/1000 Mbps)
Processor	1.4GHz dual-core processor
Memory	512 MB RAM
Security	WPA/WPA2—PSK
Dimensions	11.22 x 7.26 x 1.97 in
