NETGEAR R7500 User Manual

DescriptionLED
•
Solid. A powered-on device is connected to the Ethernet port.
•
Blinking.The port is sending or receiving traffic.
•
Off. No device is connected to this Ethernet port.
Pressing this button for two seconds turns the 2.4 GHz and 5 GHz WiFi radios
on and off.
WiFi On/Off button with LED
If this LED is lit, the WiFi radios are on. If this LED is off, the WiFi radios are
turned off and you cannot use WiFi to connect to the router.
This button lets you use WPS to join the WiFi network without typing the WiFi
password.The WPS LED blinks white during this process and then lights solid
white.
WPS button with LED
You can use the LED On/Off switch on the rear panel of the router to turn the LEDs on the top of the
router on or off. See Turn the LEDs On or Off on page 12.
Rear Panel
The rear panel connections and buttons are shown in the following figure.
Figure 3. Router rear panel
Pressing the Reset button restores the factory settings. See Factory Settings on page 181.
Hardware Setup
11

NETGEAR R7500 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC2350 (600 + 1733 Mbps)
Number of Ethernet Ports	5
Antenna	4 external antennas
Beamforming+	Yes
Dynamic QoS	Yes
MU-MIMO	Yes
VPN Support	Yes
WiFi Band	Dual Band 2.4GHz and 5GHz
Ethernet Ports Speed	Gigabit (10/100/1000 Mbps)
Processor	1.4GHz dual-core processor
Memory	512 MB RAM
Security	WPA/WPA2—PSK
Dimensions	11.22 x 7.26 x 1.97 in
