NETGEAR RangeMax WPN824 User Manual

Reference Manual for the RangeMax Wireless Router WPN824
2-6 Introduction
202-10072-01, March 2005
NETGEAR Related Products
NETGEAR products related to the RangeMax Wireless Router WPN824 are as follows:
• RangeMax Wireless USB 2.0 Adapter (WPN111)
• RangeMax Wireless PCI Adapter (WPN311)
• RangeMax Wireless PC Card (WPN511)
Package Contents
The product package should contain the following items:
• RangeMax Wireless Router WPN824.
•AC power adapter.
• Vertical stand.
• Category 5 (CAT5) Ethernet cable.
• NETGEAR RangeMax Wireless Router WPN824 Resource CD, including:
— This manual.
— Application Notes and other helpful information.
• Wireless Home Router Setup Guide.
• Warranty and Support Information Card.
If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the
carton, including the original packing materials, in case you need to return the router for repair.
The Router’s Front Panel
The front panel of the WPN824 router contains the status lights described below.
Figure 2-1: WPN824 Front Panel
Power
Internet Port
Wireless
LANPort4
Test

NETGEAR RangeMax WPN824 Specifications

General

Bandwidth	2.4 GHz
xDSL connection	Yes
Dimensions (WxDxH)	223 x 153 x 31 mm
Maximum data transfer rate	0.108 Gbit/s
Security algorithms	WPA-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
Ethernet LAN (RJ-45) ports	4

Weight and Dimensions

Weight	500 g
