NETGEAR WAC730

Advanced Configuration
93
ProSAFE Dual-Band Wireless AC Access Point WAC720 WAC730
d. The profile table shows four security profiles. Choose a security profile to edit by
selecting the corresponding radio button to the left of the profile.
e. Click Edit to configure the selected security profile settings.
The Edit Security Profile
page displays for the selected security profile. (The following figure contains an
example.)
f. Specify the settings as explained in the following table:
Setting Description
Profile Definition
Profile Name Enter a profile name that is easy to remember. The default names for the four
security profiles are NETGEAR-WDS-1, NETGEAR-WDS-2,
NETGEAR-WDS-3, and NETGEAR-WDS-4.
Remote MAC Address Enter the MAC address of the remote wireless access point (the MAC
address of
AP2 or AP 3 on LAN Segment 1 in Figure 6 on page 92).
Authentication Settings
Network Authentication
and
Data Encryption
From the Network Authentication menu, select Open System, WP
A-PSK, or
WPA2-PSK. Your selection determines the options that the Data Encryption
menu provides, and whether the WPA Passphrase (Network Key) field
displays.
WPA-PSK TKIP (T
emporal Key Integrity Protocol) is the standard
encryption method used with WPA-PSK and the only
selection possible from the Data Encryption menu.
In the WPA Passphrase (Network Key) field, enter a
passphrase.
The passphrase length needs to be between
8 and 63 characters (inclusive).
WPA2-PSK AES (Advanced Encryption Standard) is the standard
encryption method used with WP
A2-PSK and the only
selection possible from the Data Encryption menu.
In the WPA Passphrase (Network Key) field, enter a
passphrase.
The passphrase length needs to be between
8 and 63 characters (inclusive).
Note: NETGEAR recommends WPA2-PSK authentication
with AES encryption if you want to use the 11n rates and
speed.
g. Click Apply to save your security profile settings. The Bridging page displays again.
h. Repeat Step b through Step g for any other security profile that you want to edit.
For example, first configure security profile NETGEAR-WDS-1 with the MAC address
of
AP2, and then configure security profile NETGEAR-WDS-2 with the MAC address
of AP3 (see Figure 6 on page 92).
2. Activate the wireless access point (AP1 on LAN Segment 1 in Figure 6 on page 92) as a
point-to-multipoint bridge (that is, it is the master in the wireless network):
a. On the Bridging page, select the Enable W
ireless Bridging check box.
