NETGEAR WAX214 User Manual

2
Hardware Overview Model WAX214
The NETGEAR WiFi 6 AX1800 Dual Band PoE Access Point Model WAX214 is an indoor,
standalone access point.
The access point provides 802.11ax high-performance WiFi connectivity for a small
office/home office and supports dual-band concurrent WiFi 6 operations at 2.4 GHz
and 5 GHz with a combined throughput of 1.8 Gbps (about 600 Mbps at 2.4 GHz and
1200 Mbps at 5 GHz).
A single Gigabit PoE LAN port lets you connect the access point to a PoE (802.3af)
switch. If you use a regular switch, the access point requires a power adapter, which is
supplied for model WAX214PA. (For model WAX214, a power adapter is an option that
you can purchase.)
The chapter contains the following sections:
• Unpack model WAX214
• Top panel with LEDs for model WAX214
• Hardware interfaces model WAX214
• Label model WAX214
11

NETGEAR WAX214 Specifications

General

DC-in jack	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power supply	18 W
Input current	1.5 A
AC input voltage	12 V
Cables included	LAN (RJ-45)
Number of products included	1 pc(s)
Placement	Ceiling, Table, Wall
Certification	CB, EN60950, EN62368
Product color	White
LED indicators	LAN, Power, WLAN
Cable lock slot type	Kensington
Storage temperature (T-T)	0 - 95 °C
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 40 %
Number of users	128 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1773.5 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
Maximum data transfer rate (2.4 GHz)	573.5 Mbit/s
Antenna type	Internal
Antenna gain level (max)	4 dBi
Security algorithms	WPA2, WPA3
Number of SSID supported	4
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	160.9 mm
Height	33.28 mm
Weight	380 g
