NETGEAR WAX214 - Mount Model WAX214 to a Wall

Mount model WAX214 to a wall
To mount the access point to a wall:
1.
The bottom of the access point includes two holes that let you mount the access
point on two screws inserted in a wall.
2. Mark the wall where you want to insert the provided anchors and screws, which must
be 3.875 in. (98.5 mm) apart.
3.
Insert the anchors and screws, but leave about 0.25 in. (6 mm) of each screw
protruding from the wall so that you can insert the screws into the holes on the
bottom of the access point.
3.875 in. (98.5 mm)
User Manual142Mount Model WAX214 to a Wall
or Ceiling
NETGEAR WiFi 6 AX1800/AX3600 Dual Band PoE/PoE+ Access Points, WAX214 and WAX218
