NETGEAR WAX214 User Manual

Display the access point device, memory,
LAN, and WiFi status information
You can display access point device information, memory information, Ethernet LAN
information for IPv4 and IPv6, WiFi LAN information, and statistics.
To display the access point device status and other information:
1.
Launch a web browser from a computer or mobile device that is directly connected
over WiFi to the access point or connected to the same network as the access point.
2. Enter the IP address that is assigned to the access point.
If you are directly connected to the “CONFIG-ONLY” SSID, you can enter
https://www.aplogin.net.
A login window displays.
If you do not know the IP address, see Find the IP address of the access point on
page 33. For more information about the “CONFIG-ONLY” SSID, see 2.4 GHz
management SSID on page 58.
If your browser does not display a login window but displays a security message and
does not let you proceed, see Log in to the access point after you complete the initial
log-in process on page 35.
3. Enter the access point local device password and click the Login button.
The local device password is the one that you specified. The password is
case-sensitive.
The Device Status page displays.
4.
To refresh the information on the page, click the Refresh button.
The following tables describe the information on the page.
Table 4. Device Information section
DescriptionSetting
The device name (system name). For more information, see Change the device name
on page 47.
AP Name
The fixed serial number of the access point.Serial Number
The fixed MAC address of the LAN/PoE (model WAX214) or LAN/PoE+ (model
WAX218) port.
MAC Address LAN
User Manual112Monitor the access point and its
Network Connections
NETGEAR WiFi 6 AX1800/AX3600 Dual Band PoE/PoE+ Access Points, WAX214 and WAX218

NETGEAR WAX214 Specifications

General

DC-in jack	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power supply	18 W
Input current	1.5 A
AC input voltage	12 V
Cables included	LAN (RJ-45)
Number of products included	1 pc(s)
Placement	Ceiling, Table, Wall
Certification	CB, EN60950, EN62368
Product color	White
LED indicators	LAN, Power, WLAN
Cable lock slot type	Kensington
Storage temperature (T-T)	0 - 95 °C
Operating temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 40 %
Number of users	128 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1773.5 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
Maximum data transfer rate (2.4 GHz)	573.5 Mbit/s
Antenna type	Internal
Antenna gain level (max)	4 dBi
Security algorithms	WPA2, WPA3
Number of SSID supported	4
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	160.9 mm
Height	33.28 mm
Weight	380 g
