Getting to Know Your Wireless Router 3
You can use the status lights to verify various conditions.
Table 1. Status Light Descriptions
Label Activity Description
1. Power
Solid Amber
Solid Green
Blinking Amber
Blinking Green
Off
The router is performing the power-on self-test diagnostic.
The power is on and the router is ready.
A software update is in progress.
Firmware is corrupted. See “Checking Basic Router Functions” on
page 25 for instructions on restoring your router firmware.
Power is not being supplied to the router
2. Push 'N'
Connect
Solid Green
Blinking Green
Off
Indicates that wireless security is enabled.
A WPS-capable device is connecting to or managing the router.
No WPS connection exists.
3. Internet
Solid Amber
Solid Green
Blinking
Off
The Internet port is connected, but no IP address has been acquired.
The wireless router has acquired an Internet address.
Data is being communicated through the Internet port.
No Ethernet cable is connected to the modem.
4. Wireless
Solid Blue
Blinking Blue
Off
The wireless interface is enabled.
Data is being communicated over the wireless network.
The wireless interface is turned off.
5. LAN
(Ports 1–4)
Solid Green
Blinking Green
Solid Amber
Blinking Amber
Off
The local port is connected to a 100 Mbps device.
Data is being transmitted at 100 Mbps.
The local port is connected to a 10 Mbps device.
Data is being transmitted at 10 Mbps.
No link is detected on this port.
