Getting to Know Your Wireless Router 5
1. WPS button – Turns on Push ‘N’ Connect (WPS). When Push ‘N’ Connect is active and
ready to add a wireless client through WPS, the Push ‘N’ Connect LED on the front of the
wireless router is blinking. See “Push 'N' Connect” on page 3.
2. Wireless On/Off button – Turns the Wireless network on and off. When the Wireless
network is enabled, the Wireless LED on the front of the router is solid blue. See “Wireless”
on page 3.
Router Label
The label on the bottom of the wireless router shows the router’s MAC address, serial number,
security PIN, and factory default login information.
The ports on the router are color-coded to distinguish your Internet port from the other four ports
that connect to the wired computer(s) on your Local Area Network (LAN).
Figure 3
1
2
