Part-Setting Using The Part-Set Buttons
The TS790 & TS900 can have up to three predefined part-set configurations. Each configuration
allows the alarm system to set with one or more wards isolated. Each configuration is then
assigned to a part-set button A,B or C, normally this will be done by the installation company at
the time of commissioning. However the master user may also configure the part-set buttons,
providing the installation company has programmed the alarm system to allow this facility (see
“Part Set Groups on page 39).
»
To pa rt-set t he alarm system, proceed as fo llows:
1. Enter your passcode ? ? ? ?. The
display will show:
2. Within 5 seconds press the required
part-set button A, B or C, e.g., press “A”
for part-set A. The display will show:
3. The exit sounder will start. If necessary
leave the area via the prescribed exit route.
Thedisplaywillshow the remainingexittime,
e.g.,
4. The system will be part-set when the exit
time has expired, on activation of the Final
Exit circuit or by pressing the Exit Terminator
button, as appropriate. When the system is
part-set the display will show the wards that
are set and the time, e.g.,
+
The text shown on the LCD remote keypads at step (2) may be programmed by the
masteruser (see “Edit Textfor Part-Set Groups” on page 41). Ifthe text is not programmed
the display will read the default “Part Set group A” for the above example.
+
If the alarm system has LED remote keypads fitted, the installation company may have
programmed the system so that the alternating displays shown at step (4) only show the
time.
Part-Set A: _________________________________________________________
Setting Mode: Timed o Final Exit o Exit Terminator o Instant o
Part-Set B: _________________________________________________________
Setting Mode: Timed o Final Exit o Exit Terminator o Instant o
Part-Set C: _________________________________________________________
Setting Mode: Timed o Final Exit o Exit Terminator o Instant o
7
TS790 & TS900 User Manual Operating The System
Press ENT to
Select Function
LCD
FUNCTION
Starburst
Func
.
LED
Setting the
Office Area Only
P. SET A
PS.A
Please Exit Now.
Time left > 0025
0025
0025
Wards set [ A ]
05:30 Sun 28 APR
PART SET
P
.
SET
A
A
05.30
05
.
30
