Networker TS790 - Configure Wards - [2.8] (Continuation)

V iewing the System Log with an LCD Remote Keypad - [2.9]
To view the log with an LCD remote keypad, proceed as follows:
1. Ensure that “User menu 2" is selected. Press 9 to select
the View Log option. The display shows the most
recent event. The top line shows the event description (see
Table 1), and the bottom line shows the time and the date
that the event occurred on e.g.:
2. Use the A or[ keys to scroll backwards and the C key
to scroll forwards through the log, e.g., enter “A” to scroll
backwards. The display shows the previous event e.g.:
3. If the event being displayed is one that refers to a user
number, e.g.,"PASSCODE 01".Pressing the B key will toggle
between the user text (name) and user number for that
event.
4. If the event being displayed is one that refers to a circuit
number, e.g., “ALARM 02". Pressing the B key will toggle
between the circuit number and circuit text for that event.
5. Press] toleavethisoptionandreturnto“Usermenu2".
V iewing The Log With an LED or Starburst Remote Keypad - [2.9]
To view the log with an LED or Starburst remote keypad, proceed as follows:
1. Ensure that “User menu 2" is selected. Press 9 to select
the View Log option. The display will show the most recent
event (see Table 1), e.g.:
2. Use the A or[ keys to scroll backwards and the C key
to scroll forwards through the log, e.g., enter “A” to scroll
backwards. The display shows the previous event e.g.:
3. To view the time for the selected event press B once.
The display shows the time that the event occurred, e.g.,
“08.45 am”:
4. To view the date for the selected event press B again.
The display shows the date that the event occurred, e.g.,
“28 APRil”:
5. To view the minutes and seconds for the selected event
pressB again.Thedisplayshowsthe minutesand seconds
that the event occurred, e.g., “40 mins & 59 secs”:
6. To view the event description again for the selected
event press B again. The display shows the event
description again, e.g.,:
7. Press] toleavethisoptionandreturnto“Usermenu2".
LCD St arburst LED Description
31
TS790 & TS90 0 User Manual User Menu 2
PASSCODE 01
08:45.59 28/04
LCD
PASSCODE 01
08:40.59 28/04
PASSCODE Colin
08:40.59 28/04
PASSCODE 01
08:40.59 28/04
ALARM 02
06:00.59 28/04
Store Room PIR
06:00.59 28/04
USER 01
Starburst
Ur
.
01
LED
USER 01
Ur
.
01
08.40
08
.
40
2804
2804
4059
4059
USER 01
Ur
.
01
