Text Key pad
In the text mode the keypad functions as follows:
A
Up the alphabet
1
Character A
2
Character E
3
Character I
B
Change cursor
4
Character O
5
Character U
6
Number 0
C
Down the alphabet
7
Cursor left
8
Toggle case
9
Cursor right
D
Not used
[
Accept text
0
Space
]
Abandon editing
Cursor Types:
^ This character is used to represent the top line text cursor.
v This character is used to represent the bottom line text cursor.
| This character is used to represent the number cursor.
To program text Proceed as follows:
1. Text is entered by pressing one of the vowel keys and
then using the A orC keys to move up and down, e.g.,to
type the letter R press “5" to select U then press C three
times to scroll down to the letter R. The display will show:
2. Now use the 9 key to move the cursor right, repeat
step 1 for the next letter. Keep repeating steps 1 and 2 until
the whole word is formed, e.g.:
3. Numbers may be entered by pressing key “6" then using
the A or C keys to move up and down.A quicker way is to
pressB,whichchangesthe cursorto ”|"andnumbersmay
now be entered directly using the number keys, e.g., to
enter405firstpressB thenenter“405".Thedisplaywillshow:
4. When the display shows the required text press [ to
accept or press ] to abandon.
44
User Menu 3 TS790 & TS90 0 User Manual
R
^CT 02
LCD
ROOM
CCT 0^
ROOM 405
CCT 02 |
