Maintenance and troubleshooting Model 7100E
36
Revision A, dated 24-Jun-2016
Manual P/N: C5-06-4900-14-0
5.1.1.7 User Setup F: Alarm-1 and Alarm-2 relays fail-safe/Non-fail-safe action
This parameter allows the user to set the Alarm-1 and Alarm-2 relays to either failsafe action (relay coils
not powered in active alarm state) or non-failsafe (relay coils powered in active alarm state).
Valid Settings: 0 (Non-Failsafe) • 1 (Failsafe)
5.1.1.8 User Setup B: RS-232 baud rate
This parameter allows the user to set the RS-232 communications baud rate.
Valid Settings: 1 (300BPS) • 2 (1200BPS) • 3 (2400BPS) • 4(4800BPS) • 5 (9600BPS)
6 (19200BPS) • 7 (38400BPS)
5.1.1.9 User Setup 8: Factory setup restore
This parameter allows the user to return the Model 7100E to its initial factory-commissioned settings.
Always perform a gas calibration after restoring factory settings.
Valid Settings: 88. A setting of 88 will activate the Factory Setup restore.
