Safety instructions
Installation, operation, and maintenance of the unit must be performed by trained technical personnel.
Technical personnel must be authorized to perform the tasks by the owner-operator.
Electrical connections must be established by an electrical technician.
To prevent personal injury, technical personnel must read, understand, and follow all warnings and
instructions in this manual before attempting installation or operation of the unit.
If the operator cannot read these instructions, operating instructions and safety precautions must be
read and discussed in the operator’s native language.
o Si el operador no puede leer las instrucciones, las instrucciones de operación y las
precauciones de seguridad deberán leerse y comentarse en el idioma nativo del operador.
o Si l’utilisateur ne peut lire les instructions, les instructions et les consignes de sécurité doivent
lui être expliquées dans sa langue maternelle.
No operator access is permitted inside the housing. Repairs not described in the Operating
Instructions may only be performed by the manufacturer or authorized service team.
Designated use
The analyzer is a microprocessor-based instrument for oxygen measurement in clean gas
applications. It is designed to minimize all effects of static discharges and interference from RFI and
EMI emissions.
If the equipment is used in a manner other than as described, the protection provided by the
equipment may be impaired and may pose a threat to the safety of personnel.
The manufacturer does not accept liability for damage caused by improper or non-designated use.
Operational safety
Please read this manual in its entirety before attempting installation or operation! Attempting to operate
the Model 7100E without fully understanding its features and functions may result in unsafe conditions
Always use protective eye wear and observe proper safety procedures when working with
pressurized gases.
Always assure the pressure of gas entering the Model 7100E is 1-3 psig.
Always calibrate the Model 7100E at an equivalent pressure and flow rate to the measured gas.
Always allow the Model 7100E to cool down before attempting to access the sensor.
Ensure the Model 7100E has been properly calibrated before use.
Never expose the Model 7100E analyzer chassis to water, high humidity or moisture. The analyzer
chassis is not watertight.
Never expose the Model 7100E to flame or high temperatures.
Never expose the Model 7100E analyzer to flammable gases or vapors. The unit is not rated
Explosion Proof, or Intrinsically Safe.
Never expose the Model 7100E directly to unregulated gas lines, cylinder gas. High gas pressures
may cause the oxygen sensor to rupture.
Ensure the analyzer unit is mounted in an area of free airflow to prevent the chassis from exceeding
the operating temperature specifications. Do not mount the analyzer against hot surfaces. Do not
block the ventilation louver on the analyzer chassis.
