6.4 APPENDIX D – Control panel hot-key functions
For convenience in operating and troubleshooting, the Model 7100 has four control panel Hot-Key functions
that can be performed quickly via the control panel without entering the normal setup menus or the service
port user menus.
Keys pressed
Description
UP + DOWN
Return to “RUN” mode from any User mode
UP + DOWN
(hold both keys for 10 seconds*)
Run lamp test
DOWN first, then MODE
(hold both keys for 10 seconds*)
Show sensor voltage
UP first, then MODE
(hold both keys for 10 seconds*)
Restart Model 7100
* Hold all keys indicated until the 7-segment alphanumeric display shows “---“ then release the pressed keys.
To return to normal operation, press and release the same keys again.
