4.0 SET-UP
The DP8 digital readout display is equipped with a Set-Up Routine. The routine enables the operator to
change factory settings in order to increase efficiency and productivity. If the factory defaults are suitable,
select the NORMAL option at the end of the Routine to restore the factory defaults.
Generally, the entire Set-Up Routine is performed only one time. Changing some parameters in Set-Up may
alter datums, SDMs, tool compensations and Digifind.
DO NOT RUN SET-UP IF YOU ARE NOT PREPARED TO LOSE THIS DATA.
Set-Up is enabled while the unit is running its initial self-test, just after powering on. Press the [ ON/OFF ] on
the face of the display as the self-test is running.
The Set-Up procedure makes use of a menu system. The main menu consists of a list of options that can be
customised for your use (See Table 1). You simply press the [
<<
] and [
>>
] keys to scroll through this list
until you reach the option you wish to change. To change the option when selected, press [ ENT].
To exit the Set-Up routine scroll through to the quit option and press [ENT ].
If the keypad/display has been switched off by pressing the [ ON/OFF ] key rather than switching off at the
mains, it is possible to enter the Set-Up routine by pressing the [ ABS/INC ] key followed by the [ ON/OFF ]
key.
ON/OFF key
ABS/INC key
ON/OFF key This is required to complete the proper sequence as described in text
above
4.1 Set-Up Introduction
