Newall DP8 User Manual

Set-Up
Newall Measurement Systems
11
The I/P (Input) Type function allows the operator to specify
the type of transducer connected to each axis. The DP8
reads Newall's Spherosyn, Microsyn 10 or Microsyn 5
Transducers.
SEL AXIS
Options: SPHEroSn
uSn 10
uSn 5
ent
I/P TYPE
ent
Scroll through available options for each
axis using the (AXIS) key, once all axes
read the desired transducer type, select
with [ENT]
X
Y
Z
>
IMPORTANT:
The input type selected for each axis must match the
transducer connected to that axis. The DP8 will give
incorrect readings if the I/P Type does not match the
transducer installed.
(d) I/P Type
The Set-Up procedure can only entered by pressing the
[ON/OFF] during the power on sequence or by turning the
display off using [ON/OFF] and then pressing [ABS/INC]
before pressing [ON/OFF] again.
When you have entered the Set-Up routine, the letters
‘SET-UP’ appear in the top axis display.
Press the [ > ] key to move to the next menu option.
SET-UP
abs
inc
>
ENGLISH
Options: ENGLISH FRANCAIS
DEUTSCH ITALIANO
ESPANOL DANSK
CESKY
ent
LANGUAGE
BEEP O N
>
Options: BEEP O N
BEEP OFF
ent
KEY BEEP
ent
>
Scroll through the available options using
the arrow keys and select the desired
language mode with [ENT]
Toggle between Beep On and Beep Off
using the arrow keys and select desired
mode with [ENT]
>
ent
>
(a) Set-Up
(b) Language
(c) Key Beep
4.3 Set-Up Menu
Press the [ > ] key to move to the next menu option.
Press the [ > ] key to move to the next menu option.
Press the [ > ] key to move to the next menu option.
