Set-Up
Newall Measurement Systems
10
Table 1 - Set-Up Defaults
FUNCTION DESCRIPTION DEFAULT SETTING MENU OPTIONS
LANGUAGE Selects the language to display messages ENGLISH English/French/German/Spanish
Italian/Danish/Czech
KEY BEEP Enables the audible beep when keys are pressed on the keypad ON On/Off
I/P TYPE Selects the type of transducer on each axis SPHEROSYN Spherosyn/Microsyn 5/Microsyn 10
RAD/DIA Selects radius or diameter reading for each axis RAD (DIA - X axis lathe) Rad/Dia
RESOLUTION Selects the resolution to be displayed on each axis 5µm 1 / 2 / 5 / 10 / 20 / 50µm
DIRECTION Changes the direction of count for each axis 1 0 / 1
LIN COMP Enters a linear error compensation factor 1.000000 Sel Axis
(Automatic or direct entry)
SDM Enables the subdatum memory function on the keypad ON On/Off
POS OUT Enables the position pulse output function OFF Off/X Axis/Y Axis/Z Axis/
(Only available when the optional auxiliary port is included) All Axes
POS SET Sets the position that triggers a pulse output ALL ZERO Posit-1 / Posit-2 / Posit-3 /
(Only available when the optional auxiliary port is included) Reset / Pulse MS
ZERO APPROACH Enables zero approach function on the keypad OFF On/Off
ZERO SET Enables approach window to be set 0.000 User definable window
(Selectable only if zero approach is “on”)
NORMAL Sets factory defaults for the DP8 - Quit Normal/Default
QUIT Exits the Set-Up routine and saves settings to memory -
MILL OPTIONS
ARC Enables the arc contour function on the keypad ON On/Off
PCD Enables the bolt hole circle function on the keypad ON On/Off
LINE Enables line hole function on keypad ON On/Off
POLAR Enables line polar co-ordinate function on the keypad ON On/Off
LATHE OPTIONS
TOOL Enables tool offset compensation ON On/Off
SUMMING Enables summing of axes on the keypad OFF Off/ X+Z
l
/ Z+Z
l
/ Vectored
TAPER Enables Taper function on the keypad. ON On/Off
4.2 Set-Up Defaults
