Newall DP8 - 6.3 Line Hole Function

Mill Functions
Newall Measurement Systems
30
MILL FUNCTIONS
RAD - TO O L
Options: RAD - TO O L
RAD + TO O L
>
ent
0.1000
MAX CUT?
-1.3904
PT 1
-5.1098
X
Y
-5.9950
PT 65
-2.4504
X
Y
The RADIUS + TOOL calculates a toolpath which is
compensated to the outside of the Arc. RADIUS - TOOL
calculates a toolpath which is compensated to the inside
of the Arc.
Scroll through available options using the
arrow key and select internal or external
with (ENT).
1
ent
.
PT 2
MAXIMUM CUT refers to the distance between machining
points. The smaller the increment, the smoother the arc
and the more points calculated. The larger the increment,
the rougher the arc and the fewer points calculated.
The DP8 displays the distance to Point 1. The example
assumes the operator is at absolute zero. If not, the num-
bers displayed will be the calculated axes values, plus the
values of the current X, Y position relative to 0,0.
Use the arrow key to display co-ordinates for the last
point in the arc. This also displays the number of points to
be worked in the arc.
Use the arrow keys to display sequential co-ordinates for
each point along the arc. Move the work to Zero at each
point.
Line Hole Function can be accessed in either the Absolute, Incremental or Sub-Datum modes.
To enter the Line Hole function press the key.
Three axes versions will display the message LINE - XY, or XZ or YZ.
NOTE: Two axes versions will not offer the axes
selection and will directly prompt 'START'.
The rest of the sequence is identical.
LINE -XY
LINE
Options: LINE - XY
LINE - XY
LINE - Y Z
>
ent
Scroll through available options using the
arrow key and select your option with (ENT).
6.3 Line Hole Function
>
>
<
><
