Newall DP8 - 6.4 Polar Co-ordinates

Mill Functions
Newall Measurement Systems
31
X
Y
0
0
Length 30.0
Angle 45
o
Start Point (10,10)
10.000
START
0
ent
30.000
LENGTH
>
4
NO. HOLES
4
ent
>
45.000
ANGLE?
5
ent
>
-10.000
HOLE 1
>
-10.000
4
Position the X and Y axes until both displays
read Zero. This is the first hole location
HOLE 2
< >
Use the arrow keys to display co-ordinates for
subsequent holes in the routine. Work to zero for each
hole location.
10.000
1
0
ent
1
0
ent
3
The Polar co-ordinate function enables the operator to convert the displayed data from the conventional
Cartesian co-ordinates (X,Y,Z) to Polar (Length + Angle) co-ordinates for any plane XY, XZ or YZ.
Pressing the switches between the two displays.
The can be selected from the Absolute, Incremental or Sub Datum modes.
-
20.0000
15.0000
Assume the adjacent Cartesian (x,y,z) co-ordinates are
displayed
6.4 Polar Co-ordinates
EXAMPLE:
The keystrokes for entering the following Line Holes are
shown. X and Y axes are assumed at Absolute Zero.
NOTE: Length is the total length of the line hole
sequence, not the distance between adjacent
holes.
X
Y
