Introduction
Newall Measurement Systems
2
1.0 INTRODUCTION
The DP8 Digital Readout conforms to the relevant European standards for electromagnetic compatibility and
low voltage directive as detailed below.
BS EN 50081-2:
Electromagnetic compatibility.
Generic Emission Standard - Industrial Environment
BS EN 50082-2: Electromagnetic compatibility.
Generic Immunity Standard - Industrial Environment.
BS EN 61010-1: Safety requirements for electrical equipment for
measurement, control and laboratory use.
Construction: Two part system - display/keyboard separate from DSU/Inputs
Dimension Display/Keyboard DSU
Height: 170mm (6.7in) 130mm (5.1in)
Width: 295mm (11.6in) 185mm (7.3in)
Depth: 30mm (1.2in) 60mm (2.4in)
Weight: 2.1kg (4.6lbs) 1.7kg (3.7lbs)
Operating Voltage: 115 or 230V (switch selection)
Supply Voltage Fluctuation: Not to exceed +/-15% of the operating voltage
Supply Frequency: 50 to 60 Hz
Maximum Power Consumption: 26VA
Operating Temperature: 0 to 45°C (32°F to 113°F)
Storage Temperature: -20 to 60°C (-4°F to 140°F)
Inputs: Dependant on model, two or three Spherosyn/Microsyn transducers
Resolution:
Spherosyn/Microsyn 10 5µm (0.0002in) / 10µm (0.0005in) / 20µm (0.001in) / 50µm (0.002in)
Microsyn 5 1µm (0.00005in) / 2µm(0.0001in) / 5µm (0.0002in) / 10µm (0.0005in)
Environmental Conditions: Indoor Use, IP20 (IEC 529)
Relative humidity - maximum 80% for temperatures up to 31°C (87.8°F),
decreasing linearly to 33% at 45°C (113°F).
Transient overvoltage according to INSTALLATION CATEGORY II of IEC664
POLLUTION DEGREE 2 in accordance with IEC664
NEWALL MEASUREMENT SYSTEMS LIMITED RESERVES THE RIGHT TO CHANGE SPECIFICATION
WITHOUT NOTICE
Certificate No FM36096
1.1 EMC and Low Voltage Compliance
1.2 Technical Specifications
