SET-UP
Normal returns all the Set-Up Options to the original
factory settings (Except language setting).
DEFAULT
Options: DEFAULT
QUIT NORMAL
NORMAL
Toggle between Default and Quit Normal
using the arrow keys and select desired
mode with [ENT]
ent
>
ent
>
WARNING!
Selecting DEFAULT will cancel all changes made
during set-up. The DP8 will return to the original
factory settings. Select QUIT NORMAL to leave
the settings unchanged.
Quit exits the Set-Up procedure and returns the DP8 to
operational use.
Returns to normal operating mode.
QUIT
QUIT
ent
The Position Set function is only available on DSU’s which
have been fitted with the optional auxiliary output.
The function allows the operator to set parameters for
each axis specified as output during the Position Pulse
Output Set-Up.
Press the [ > ] key to move to the next menu option.
POSIT - 1
Options: POSIT-1 RESET
POSIT-2 PULSE MS
POSIT-3
POS SET
Scroll through available settings using the
arrow key, Load the relevant axes with the
required data.
ent
>
ent
>
The Position Pulse Output function is only available on
DSU’s which have been fitted with the optional auxiliary
output.
The function provides the operator with a way to control
external devices such as relays or PLCs using the DP8.
Setting Position Pulse Output to X AXIS, Y AXIS, Z AXIS
or ALL AXES activates the feature for the selected axis.
NOTE: For the Lathe version, Y AXIS refers to the Z
AXIS and the Z AXIS refers to the Z
l
AXIS.
Press the [ > ] key to move to the next menu option.
ALL AXES
Options: OFF
X AXIS
Y AXIS
Z AXIS
ALL AXES
POS OUT
Scroll through available options using the
arrow keys and select the desired axis
with (ENT).
ent
ent
>
(s) Position Pulse Output (Auxiliary Option only)
(t) Position Set (Auxiliary Option only)
(u) Reset to Original Factory Settings
(v) Quit Set-Up
IMPORTANT!
This is only available with the optional auxiliary version
and is detailed in Section 8.0
IMPORTANT!
This is only available with the optional auxiliary version
and is detailed in Section 8.0
