STANDARD FUNCTIONS
0.0000
SDM 1
0.0000
sdm
zero
Establish absolute zero at the lower corner of the part.
Move to the first position and change to SDM 1. Press
[ SDM ZERO ]. This will store the current machine position
in the selected SDM and will zero all axes. The current
position is now stored as SDM 1.
SDM 3
The next move is Absolute. Select the [ABS/INC] key and
move to the position. Select a new SDM number and store
the position with [ SDM ZERO ].
0.0000
SDM 3
0.0000
sdm
zero
1.2000
ABS
1.2000
abs
inc
<
>
Scroll to the next SDM by using the arrow
keys. Alternatively, use the [SDM] key to
select a new SDM.
IMPORTANT:
The dimensions in the display may change after you
select the SDM number even though the machine has
not moved. The numbers are the last dimensions stored
in that particular SDM and should be ignored. Pressing
[ SDM ZERO ] will store the actual current position
in the SDM block.
abs
inc
Repeat this procedure to store SDM #3 into memory.
NOTE: If the next move is Incremental, move to the
position, select a new SDM number, and store
the position with [SDM ZERO]
To exit SDM function, select [ABS/INC].
