STANDARD FUNCTIONS
JOB NO?
Job numbers can be entered up to 4 digits eg: 1234
ent
Enter a job number.
Confirm with Enter
JOB 1234
All the higher numbered Sub Datums are shifted by one
place. i.e. The sub datum figures from SDM10 become
SDM11, SDM11 become SDM12 etc.
NOTE: If SDM199 contains data, then that data will be lost
The Sub Datum containing the job number has no axes
data.
The message screen displays 'JOB 1234'
and the axes displays become blank
3
4
2
1
Pressing [ ABS/INC ] will exit the function.
abs
inc
(b) To add a Job End statement
The procedure is similar to entering a Job Number, except as follows:
INS SDM
All the higher numbered Sub Datums are shifted by one
place. i.e. The Sub Datum figures from SDM15 become
SDM16, SDM16 become SDM17 etc.
NOTE: If SDM 199 contains data, then that data will be
lost.
The Sub Datum containing the job end marker has no
axes data.
Pressing [ ABS/INC ] will exit the function.
Press INS key. Use the arrow keys to scroll
through the message screen to ‘Insert Job’
ins.
JOB END
ent
After 'INS END' is displayed pressing the
ENT key will inset the statement
abs
inc
(c) Searching for a Job Number
The procedure is similar to finding a Sub Datum, except as follows:
SDM NO?
sdm
Enter the Sub Datum function by pressing
the SDM key. The message screen prompts
for the Sub Datum number.
Pressing the right arrow key changes the
message screen to ‘JOB NO?’
>
SDM NO?
sdm
ent
Select the Sub Datum immediately following
the last Sub Datum in the sequence to be
grouped e.g. SDM15
1
5
15
SDM 15
<
>
X
Z
Y
