STANDARD FUNCTIONS
(c) To insert a SubDatum
The process for inserting a Sub Datum is similar to inserting a Job Number (Section 5.4.3 (a)) except when
the Sub Datum is selected do not press [ > ] to access the Insert Job mode ‘INS JOB?’.
SDM NO?
sdm
Select the Sub Datum Function [ SDM ].
INS SDM?
Again, all the higher numbered Sub Datums will be shifted
one place up and any stored data in SDM 199 will be lost.
Proceed to enter the sub datum as described in Sections
5.4.1 or 5.4.2
Pressing [ ABS/INC ] will exit the function.
ins.
abs
inc
Select [ INS ] to enter insert mode.
SDM 5
ent
5
5
SDM 5
ent
