Lathe Functions
Newall Measurement Systems
37
LATHE FUNCTIONS
ANGLE?
1+1
30.000
X
Z
Z’
Press the [ 1+1 ] key to select the Vectoring function.
The message screen display prompts the operator to enter
the angle of the tool axis.
The Z axis displays the last entered angle. Change the
angle if necessary and enter the figure. Press [ ENT]
Z
I
VEC X.Z
1+1
0.000
10.866
11.000
X
Z
Z’
Pressing the [ 1+1 ] icon returns to the original (non
vectored) axes display.
NOTE: As for summing (Section 7.3), axis displays
can be zeroed or loaded with a value in the
vectored mode.
ent
1.000
10.000
10.000
X
Z
Z’
3 0
Press [ ENT ] (or [ 1+1 ] again) to accept the angle.
NOTE: The X axis (Cross axis) is set to read DIA in
this example
