WARNING!
SEALED BATTERIES MUST NEVER BE STORED IN A DISCHARGED OR
PARTIALLY DISCHARGED STATE.
EXTREME TEMPERATURE, UNDER- AND OVERCHARGE AND
OVERDISCHARGE WILL DESTROY BATTERIES!
1.3.5.2 Storage of UPS
If you plan to store the UPS prior to use, keep the UPS unpacked in a dry, clean and cool storage room with an
ambient temperature between (+5 °C to +40°C) and humidity of less than 90%.
If the packing container is removed protect the UPS from dust.
NOTE!
THE UPS SYSTEM, THE BATTERY CABINET AND THE BATTERIES ARE HEAVY
AND MAY TIP DURING TRANSPORTATION CAUSING SERIOUS INJURY IF
UNPACKING INSTRUCTIONS ARE NOT CLOSELY FOLLOWED.
1.4
SITE PLANNING AND POSITIONING
1.4.1 PLANNING BEFORE THE INSTALLATION
The equipment must be installed and transported in a upright position. The equipment requires space to
bottom/front and back to enable cooling airflow. It is required to arrange ventilation of the UPS room.
All parts of the UPS for service and user access are accessible from the front and rear, making it a service-friendly
and maintenance-friendly UPS. Reserve enough space from the front (min. 900 mm)
The UPS should be located where:
• Humidity (< 90 % non-condensing) and temperature (+15° and +25°C ) are within prescribed limits
• Fire protection standards are respected
• Cabling can be performed easily
• Available front accessibility for service or periodic maintenance
• Requested air cooling flow should be granted
• The air conditioning system should have sufficient amount of air cooling needed to keep the max. room
temperature rise at desired level:
• Dust or corrosive/explosive gases must be absent
• The place is vibration free
• Only front access is necessary for service and maintenance.
• If the UPS will be installed in bayed enclosures, partition walls have to be installed as well.
An ambient temperature of 15 to 25 Celsius degrees is recommended to achieve a long life of the UPS and
batteries. The cooling air entering the UPS must not exceed +40 °C. Avoid high ambient temperature, moisture and
humidity. The floor material should be non-flammable and strong enough to support the heavy load.
1.4.2 POSITIONING OF UPS AND BATTERY CABINET
1.4.2.1 Final Transport
Check before transporting the surface loading and use a adequate forklift to move the equipment to the final
position.
