UPS
Frames
Battery
Cabinet
UPS
Frames
10.11 INSTALLATION PLANNING
Clearances X Y
Minimum 200 mm 900 mm
UPS Frame type
Cabinet A Cabinet B Cabinet C CBATT-C
Dimensions (WxHxD) mm
345x720x710 345x1045x710 440x1400x910 480x1400x940
Accessibility
Top / Rear / Right+Left side: Cabinet A & B
Top / Front / Right+Left: Cabinet C
Positioning Min. 200 mm rear space (required for fan)
Input and Output Power Cabling From the bottom on the rear side
10.11.1 HEAT DISSIPATION PER UPS RANGE WITH NON-LINEAR LOAD
UPS Range 10kVA 15kVA 20kVA 25kVA 30kVA 40kVA 50kVA
Heat Dissipation with 100% Non-linear
Load per range (EN 62040-3)
W 600 900 1100 1400 1700 2300 2900
Heat Dissipation with 100% Non-linear
Load per range (EN 62040-3)
BTU/h 2048 3072 3754 4778 5802 7850 9898
Airflow (25° - 30°C) with 100% Non-
linear Load per range
(EN 62040-3)
m
3
/h 150 150 150 150 570 570 570
Heat Dissipation without load W 120 150 150 170 250 300 350
X
X
Figure 1: UPS space recommendation
Figure 2 : UPS + Battery space recommendation
Y
Y
