Newave PowerScale - Battery Characteristics

Section-10
www.newavenergy.com
04-1206_S10_NW_TDSPS_10-50kVA_GB_110201.DOC Page 7/19
Printed in Switzerland – Modifications reserved
10.4 BATTERY CHARACTERISTICS
10kVA 15kVA 20kVA 25kVA 30kVA 40kVA 50kVA
UPS Range
Cabinet Type
A B A B A B B C C C C
Min/Max number of 12V
Battery Blocks per string
No. 16-50(*) 20-50(*) 24-50(*) 20-50(*) 24-50(*) 16-50(*) 18-50(*) 30-50(*)
Maximum Battery
Charger Current
A 4A 6A
Battery Charging Curve Ripple free ; IU (DIN 41773)
Temperature compensation
ready
Standard (temp. sensor optional)
Battery Test Automatic and periodically (adjustable)
Battery Type Maintenance free VRLA or NiCd
Note : (*) Depending of the effective load in kW used by system (see table below and table in chapter 10.10.1).
Max no. for internal batteries is 48, max no. for extern batteries is 50
Description
Cabinet Type
Maximum Power in [kW]
68
9
68
9
8 1012 13.5 8 1012 13.5 9 121618 9 121618121620 22.5
Minimum number of battery
blocks
p
er Strin
g
20 22
24
16 22
24
22 28 32 34 22 28 32 34 24 28 32 36 24 28 32 36 24 32 40 46
Maximum number of
battery blocks intern the
PSC cabinet
48 48
48
2x
48
2x
48
2x
48
48 48 48 48
2x
48
2x
48
2x
48
2x
48
48 48 48 48
2x
48
2x
48
2x
48
2x
48
2x
48
2x
48
2x
48
2x
48
20 kVA
B
25 kVA
BAB
15 kVA
A
10 kVA
BA
Description
Cabinet Type
Maximum Power in [kW]
12 16 20 22.5 16 20 24 27 18 25 32 36 30 35 40 45
Minimum number of
batter
y
blocks
p
er Strin
g
24 32 40 46 16 20 24 28 18 26 32 36 30 34 40 46
Maximum number of
internal battery blocks 7/9
Ah
3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48 3x48
Maximum number of
internal battery blocks 28
Ah
1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48 1x48
25 kVA
C
50 kVA
C
30 kVA 40 kVA
CC
