NewLine RS+ Series User Manual

78
Function
Querying codes
Return codes
Backlight
brightness
7F 08 99 A2 B3 C4 02 FF 01 49 CF
7F 09 99 A2 B3 C4 02 FF 01 49
XX CF
XX indicates the value of backlight
brightness (0 - 100), corresponding to
the hexadecimal number system (00 -
64).
Backlight
status
7F 08 99 A2 B3 C4 02 FF 01 81 CF
7F 08 99 A2 B3 C4 02 FF 01 81
XX CF

XX = 00 indicates the backlight is
on.

XX = 01 indicates the backlight is
off.
Screen lock
status
7F 08 99 A2 B3 C4 02 FF 01 84 CF
7F 08 99 A2 B3 C4 02 FF 01 84
XX CF

XX = 01 indicates screen lock status .

XX = 00 indicates exit screen lock
status.
Whiteboard
state
7F 08 99 A2 B3 C4 02 FF 01 83 CF
7F 08 99 A2 B3 C4 02 FF 01 83
XX CF

XX = 01 indicates the whiteboard
state.

XX = 00 indicates non-whiteboard
state.
Return to
system state
of the
previous
options
7F 08 99 A2 B3 C4 02 FF 0A 00 CF
7F 08 99 A2 B3 C4 02 FF 0A 00
AB CD EF GH IJ KL MN OP QR
ST UV CF

AB: Power supply

CD: Speaker

EF: Current signal source

GH: Speaker volume

IJ: D.Mode

OP: Backlight brightness

QR: Backlight state

ST: Whiteboard state

UV: Screen lock state
