NDiS B533 User Manual
Chapter 3: System Setup
Installing a SO-DIMM
2. Push the ejector tabs which are at the ends of the socket outward. This
indicates that the socket is unlocked.
1. Locate the DIMM socket on the board.
DIMM sockets
