Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
32
NDiS B533 User Manual
Chapter 3: System Setup
Antenna
3. Attach the RF cables onto the Wi-Fi module, then mount the antenna
jacks to the antenna holes located at the rear panel of the chassis. Then
connect the external antennas to the antenna jacks.
