29
Step 4:
Insert the left hand pin into the lowest
hole on the rear rigging assembly,
marked ground stack dolly, to x the
cabinet in place.
For additional cabinets follow steps 7
to 9 of the ground stack instructions
(section 4.6).
Note: Always use a safety
strap when deployed in a
ground stack conguration.
Maximum number of cabinets
to be stack on the dolly is four.
4 Mechanical Congurations
