2.4 Specications
Frequency Response (-6dB) 58 Hz - 19000 Hz
Low Frequency Extension
(-10dB)
54 Hz
Nominal Coverage (-6dB) 100° (300 Hz - 16 kHz) x 10°
RMS Power 2000 W (LF: 1550 W | MF: 275 W | HF: 175 W)
Amplier Technology 3-Channel UMAC Class D - Full Bandwidth PWM Modulator With Ultra-Low
Distortion
DSP Technology 96 kHz / 40 bit SHARC DSP
Latency 1.5 ms
DSP Adjustable Parameters Filters: PEQ, FIR, hi/lo-shelving, all-pass, band-pass, hi/lo-pass | Limiters: RMS
Voltage, Peak Voltage | Groups: Mute, Delay, Level, Polarity, EQ
DSP Presets 24
Delay Adjustment 500ms (172m) on Input + 400ms (138m) on Groups
Control Type Control via LCD and Encoder on the Back Panel | Control via Software using
Ethernet - Max. Cable Length 70m
Maximum SPL (calculated) RMS: 136dB | Peak: 142dB (Full-Space)
Low Frequency Driver 2 x 10” / 3” VC, Neodymium, B&C Custom Speaker
High Frequency Driver 1 x 1.4” Neodymium Coaxial Ring Radiator Driver (MF: 3” VC | HF: 2” VC)
Audio Signal Inputs/Outputs Analogue | AES (AESOP)
Input/Output Connectors 1 x XLR | 1 x Neutrik EtherCON
®
Protections Clip Limiter | Temperature | Over Current | DC Protection | HF Protection
Operating Temperature Range 0° C - 40° C
Cooling Type External Aluminium Heat Sink with Internal Speed Controlled Fan
Power Supply UREC Universal Mains Switch Mode Power Supply (SMPS) with Power Factor
Correction (PFC) and Standby Converter
Power Input AC 100V - 240V 50Hz/60Hz
Mains Connector Dual (IN/OUT) Neutrik powerCON TRUE1 TOP
®
Power Consumption 275W
Recommended Subwoofer LAs518A
Special Features Speaker Cabinet Auto-Identication via Software
Fittings 3-Point Adjustable Rigging System (0° to 10° with 1° Step)
Handles 1 on Each Side, 2 on the Back
Grille Black Perforated Steel
Construction 15mm Multi-Laminate Birch Plywood
Finish Semi-Matte Black Textured Coating
Dimensions (WxHxD) 720 x 350 x 550 mm (28.3” x 13.8” x 21.7”)
Net Weight 37 kg (81.6lb)
Shipping Weight 40 kg (88.2lb)
