4.2.1 Ground Stack on LAs518A
Step 1:
Attach the ground stack bracket to
the LAs518A using the M20 fastener
provided.
Step 3:
Remove both pins from the rear of the
bracket assembly and remove the link
from the bracket.
Step 2:
Attach a safety strap.
Step 4:
Remove both pins from the front of
the LA210x. Lower the cabinet into
position and x into place with the
front pins.
4 Mechanical Congurations
