Step 1. Unpacking and accessories.
After open the gift box, you should check up and find the following items.
- Digital HD-STB
- Universal Remote Control
- 2 Batteries AAA (LR03) size
- User Manual
- SD A/V Cable (Yellow/White/Red) & HD Video Cable (Green/Blue/Red)
If you find a missing or broken parts, then ask your supplier or contact the service
center.
Step 2. Remove protective plastic film.
Remove protective plastic film from HD-STB top cover.
Step 3. Connect ANT Cable.
Connect external ANT cable to ANT IN.
Connect another ANT cable between LOOP OUT of HD-STB and ANT IN of TV for
analog reception.
Step 4. Connecting the Video.
Prepare HD-STB and HDTV you want to connect.
There are several methods to You should find the correct
connection method for your HDTV. Please Video Connection Diagram.
Step 5. Connecting the Audio.
Prepare HDTV or Audio equipment you want to connect.
If you are using HDMI connection, you do not need audio connection.
There are four different connection methods for Audio connection. For general TV
analog audio connection, it has Audio L/R.
For digital audio connection, you should prepare Optical Audio cable for optical audio
connection with Home Theater Equipment.
If your Home Theater Equipment system has coaxial digital input, you can use well-
shielded RCA cable for coaxial audio connection.
Step 6. Connecting the Power.
Plug the Power Cord to wall AC outlet. The power source is AC 180-250V~, 50/60Hz.
This unit is designed for continuous operation. Switching it off does not disconnect it
from the AC outlet. To disconnect this HD-STB from AC outlet, you have to AC POWER
SWITCH Off at the rear panel or unplug the HD-STB.
Step 7. Display Mode Setup.
The default display mode is native 1080i. If you need change the display mode, press
the " DISPLAY MODE" button at the front panel. Press UP or DOWN button at the front
panel to select desired display mode. Press "OK" button to confirmed display mode
Change.
connecting the video.
refer to the
17
Getting Started
