3.3 Main function
Top data is relative Wind angle, [AWA] (Apparent Wind Angle). As an
alternative to [AWA] the following can be displayed:
[AWS] (Apparent Wind Speed).
[TWA] (True Wind Angle) if the log transducer is connected.
[TWS] (True Wind Speed) if the log transducer is connected.
To change between these functions, see C12, 5.1.2.
3.4 Analogue function
Change Wind scale between 180°° and 60°° with MODE . Selected scale
is shown with the LCD arrow pointing at scale.
The text [APP] displays selected main function as apparent Wind angle
or Wind speed.
MIX 180°° The text MIX 180° means that both APP and TRUE Wind
angle is displayed in scale 180°.
MIX 60°° The text MIX 60° means that both APP and TRUE is
displayed in scale 60.
The scale can be altered between 60° and 180° to get more accurate
readings. At scale 180° each sector represent 5° and at scale 60° each
sector represent 1
2
/
3
°. See the example below .
4: OPERATION
WIND
