Menu 1.12 [N] Return
Return to menu 1.0.
2.0 [N] Supply temp.
Menu 2.1.0 [N] Heating settings
Heating settings are made in the sub-menus for this menu.
Menu 2.1.1 [N] Offset heating/Total
The selected heating curve offset is shown here.
The total offset of the heat curve is also shown here. It in-
cludes schedule, outer compensation and any room con-
trol.
NOTE
The value is changed using the “Heating curve offset”
knob.
Setting range: -10 – 10
Menu 2.1.2 [N] Heating curve
The selected curve slope (heating curve) is shown here. At
value 0, the function "Own curve" is activated, see menu
2.1.3.0.
Setting range: 0 – 20
Factory setting: 9
Menu 2.1.3.0 [U] Own heating curve
Here you can select your own curve definition. This is an
individual linear curve with one break point. You select a
break point and the associated temperatures.
NOTE
The "Curve slope” in menu 2.1.2 must be set to 0 to
activate this function.
Menu 2.1.3.1 [U] Supply temp.at +20
The supply temperature at an outdoor air temperature of
+20 °C is selected here.
Setting range: 0 – 80* ｰC
Factory setting: 20 °C
Menu 2.1.3.2 [U] Supply temp.at -20
The supply temperature at an outdoor air temperature of
-20 °C is selected here.
Setting range: 0 – 80* ｰC
Factory setting: 35 °C
Menu 2.1.3.3 [U] Buckling temperature
Here you select at what outside air temperature the break
point shall occur.
Setting range: -15 – 15 °C
Factory setting: 0 °C
Menu 2.1.3.4 [U] Supply t. at buckl.
You set the required flow temperature for the break point
here.
Setting range: 0 – 80* ｰC
Factory setting: 30 °C
Menu 2.1.3.5 [U] Return
Return to menu 2.1.3.0.
Menu 2.1.4 [U] Min supply heating
The set minimum level for the supply temperature to the
climate system is shown here.
The calculated flow temperature never drops below the
set level irrespective of the outdoor temperature, curve
slope or offset heating curve.
Setting range: 20 – 65 °C
Factory setting: 25 °C
Menu 2.1.5 [U] Circ-pump speed heat
The speed of the heating medium pump during house
heating is selected here.
Setting range: 1 – 100
Factory setting: 60
Menu 2.1.6 [N] Return
Return to menu 2.1.0.
Menu 2.2.0 [N] Cooling settings
Cooling settings are made in the sub-menus for this menu.
Menu 2.2.1 [N] Offset cooling/Total
The selected cooling curve offset is changed here.
The total offset of the cooling curve is also shown here. It
includes schedule, outer compensation and any room
control.
Setting range: -10 – 10
Factory setting: -1
Menu 2.2.2 [N] Cooling curve
The selected curve slope (cooling curve) is shown here. At
value 0, the function “Own curve” is activated, see menu
2.2.3.0.
Setting range: 0 – 3
Factory setting: 1
Menu 2.2.3.0 [U] Own cooling curve
Here you can select your own curve definition.
NOTE
The "Curve slope” in menu 2.2.2 must be set to 0 to
activate this function.
Menu 2.2.3.1 [U] Supply temp.at +20
The supply temperature at an outdoor air temperature of
+20 °C is selected here.
Setting range: 0 – 25* ｰC
Factory setting: 20 °C
Menu 2.2.3.2 [U] Supply temp.at +40
The supply temperature at an outdoor air temperature of
+40 °C is selected here.
Setting range: 0 – 25* ｰC
Factory setting: 10 °C
* Limited by menu 2.3 Max supply temp.
NIBE™ SPLIT ACVM 27050
Miscellaneous
