Dockings
General
NIBE SPLIT ACVM 270 can be connected in several different
ways, some of which are shown on the following pages.
For more detailed docking descriptions, see www.nibe.eu.
Installation requirements
AMS 10-12AMS 10-8
0.25 MPa (2.5 Bar)Max pressure, climate system
55/45 °CHighest recommended supply/return temperature at dimensioned outdoor
temperature
+65 °CMax temperature in ACVM 270
+58 °CMax flow line temperature with compressor
+7 °CMin supply temperature cooling
+25 °CMax supply temp. cooling
80 l50 lMin volume, climate system during heating, cooling*
100 l80 lMin volume, climate system during under floor cooling*
0.57 l/s0.38 l/sMax flow, climate system
0.29 l/s0.19 l/sMin flow, climate system, 100 % circulation pump speed (defrosting flow)
0.15 l/s0.12 l/sMin flow, heating system
0.20 l/s0.16 l/sMin flow, cooling system
ACVM 270Docking external addition
9–18 kWOutput external addition
0.17–0.22 l/sRecommended docking flow
+65 °CMax temperature from external heat source
* Regards circulating volume
External circulation pump must be used when the pressure drop in the system is greater than the available external pressure.
In such cases, a bypass line with non-return valve must be installed.
Overflow valve must be used if min. system flow cannot be guaranteed.
Symbol key
MeaningSymbol
Venting valve
Shut-off valve
Non-return valve
Control valve
Safety valve
Temperature sensor
Expansion vessel
Pressure gauge
