Menu 3.6.1 [U] Supply temp.at +20
The supply temperature at an outdoor air temperature of
+20 °C is selected here.
Setting range: 0 80* C
Factory setting: 20 °C
Menu 3.6.2 [U] Supply temp.at -20
The supply temperature at an outdoor air temperature of
-20 °C is selected here.
Setting range: 0 80* C
Factory setting: 35 °C
Menu 3.6.3 [U] Buckling temperature
Here you select at what outside air temperature the break
point shall occur.
Setting range: -15 15 °C
Factory setting: 0
Menu 3.6.4 [U] Supply t. at buckl
You set the required flow temperature for the break point
here.
Setting range: 0 80* C
Factory setting: 30 °C
Menu 3.6.5 [U] Return
Return to menu 3.6.0.
Menu 3.7 [U] Supply/Return temp 2
The present actual flow and return line temperatures for
climate system 2 are shown here.
Menu 3.8 [N] Return
Return to menu 3.0.
4.0 [N] Outdoor temp.
Menu 4.1 [N] Outdoor avg. temp.
This menu shows the average outdoor temperature accord-
ing to the set value in menu 4.2 (factory setting: 24h).
Menu 4.2 [U] Outdoor filter time
Here you select how long the average temperature in
menu4.1 is to be calculated.
Setting range: 1 min, 10 min, 1h, 2h, 4h, 6h, 12h, 24h
Factory setting: 24 h
Menu 4.3 [U] Outdoor avg. 1min.
Shows the average outdoor temperature over the last
minute.
Menu 4.4 [N] Return
Return to menu 4.0.
5.0 [N] Heat pump
Menu 5.1 [N] Number of starts
The accumulated number of starts with the compressor
in AMS 10 is shown here.
Menu 5.2 [N] Run time compressor
The accumulated time that the compressor has been used
in AMS 10 is shown here.
Menu 5.3 [U] Time to start
Time until the compressor start in the AMS 10 is shown in
this menu.
Menu 5.4 [U] Outdoor temp. Tho-A
This menu shows the outdoor air temperature that the
heat pump measures.
Menu 5.5 [U] Heat Ex Tho-R1
This menu shows the evaporator temperature in the heat
pump at sensor Tho-R1.
Menu 5.6 [U] Heat Ex Tho-R2
This menu shows the evaporator temperature in the heat
pump at sensor Tho-R2.
Menu 5.7 [U] Suction temp. Tho-S
This menu shows the suction gas temperature in the heat
pump.
Menu 5.8 [U] Hot gas Tho-D
This menu shows the hotgas temperature in the heat
pump.
Menu 5.9 [U] Liquid line temp.
This menu shows the liquid line temperature in the heat
pump.
Menu 5.10 [U] Condensor out / max
Shows the current and max. allowed temperature after
the condenser.
Menu 5.11 [U] HP
The current high pressure and corresponding temperature
during heating are shown here. During cooling, the actual
low pressure and corresponding temperature are shown.
Menu 5.12 [U] LP LPT
The current low pressure is shown here.
Menu 5.13 [U] Fan speed
No function.
Menu 5.14.0 [U] CompFreq act/set
The actual and set point value for the compressor fre-
quency are shown here.
Menu 5.14.1 [U] OU current CT
The present phase current to AMS 10 is shown here.
Menu 5.14.2 [U] Inverter temp Tho-IP
The current inverter temperature is shown here.
Menu 5.14.3 [U] Return
Return to menu 5.14.0.
Menu 5.15.0 [S] OU communication
Readings regarding any communication errors can be
made in the sub-menus to this menu.
Menu 5.15.1 [S] Com. error rate
Shows the percentage of incorrect communications with
AMS 10 since start-up.
* Limited by menu 2.3 Max supply temp.
NIBE™ SPLIT ACVM 27052
