Alarm list
Acknowledging alarms
No harm in acknowledging an alarm. If the cause of the
alarm remains, the alarm recurs.
When an alarm has been triggered, it is acknowledged
in menu 9.7 (service menu) by switching ACVM 270 off
and on using the switch (SF1). Note that when the power
is switched on there is a 30 minute delay before the heat
pump restarts.
When the alarm cannot be reset using the switch (SF1),
the operating mode, "Add. heat only", can be activated
to return to a normal temperature level in the house.
This is most easily carried out by holding the ”Operating
mode” button pressed in for 7 seconds.
NOTE
Recurring alarms mean that there is a fault in the in-
stallation.
Alarm with automatic reset
Resets alarmTriggers alarmAlarm text on the dis-
play
Alarm
no.
- When condenser supply is greater than 14 °C
during cooling.
When condenser supply (BT12) is less than 5 °C.Low condenser out70
- When defrosting has ended. If the defrosting
caused the alarm (condenser supply during de-
frosting is approx. 10 °C).
- When condenser out is lower than 51 °C.When condenser supply is greater than 60 C
and more than 120 seconds have passed since
shifting to the climate system.
High KF71
- When the low pressure is greater than 0.83
MPa (8.3 bar) and condenser out is greater than
14 degrees.
When the low pressure is less than 0.65 MPa
(6.5 bar) in cooling mode.
Anti freeze HX72
- When the outdoor temperature rises above 1
°C.
When the outdoor temperature drops below 0
°C and the operating mode does not permit
heating.
Freeze prot73
- When the current output decreases.Too high current output from the house.Current limit75
- When the fault has been corrected.Failed communication to one or more boards.Com. alarm76
- When defrost has ended.When the temperature in the water heater is
too low (low pressure is less than 0.5 MPa, 5.0
bar) during defrost.
Defrosting interrupted77
- When defrost has ended.Exceeded limit valueProtection78
Temperature limiter alarm
The following alarm blocks both AMS 10 and addition.
May be due toDescriptionAlarm text on the dis-
play
Alarm
no.
- The temperature limiter has tripped during
transportation
Temperature limiter in ACVM 270 has tripped.TB alarm3
- High temperature in ACVM 270
- Tripped circuit fuse (L2
ACVM 270 alarm
The following alarms block AMS 10. Addition runs at min permitted supply temperature.
May be due toDescriptionAlarm text on the dis-
play
Alarm
no.
- Tripped circuit fuse (L2) and (L3)No voltage to the outdoor unit from ACVM 270.OU power failure4
- Tripped miniature circuit breaker (-FA2)
- Low temperature during coolingToo low temperature out from the condenser.Low condenser out5
- Low flow during coolingOccurs if alarm 70 occurs 3 times within an hour.
61NIBE™ SPLIT ACVM 270
Miscellaneous
Alarm list
