Menu 5 - SERVICE
Overview
5.1.1 - hot water settings *5.1 - operating settings5 - SERVICE
5.1.2 - max flow line temperature
5.1.3 - max diff flow line temp.
5.1.4 - alarm actions
5.1.5 - fan sp. exhaust air *
5.1.7 - br pmp al set.
5.1.8 - operating mode brine pump
5.1.9 - brine pump speed
5.1.10 - op. mod heat med pump
5.1.11 - pump speed heating medium
5.1.12 - internal electrical addition
5.1.14 - flow set. climate system
5.1.22 - heat pump testing
5.1.24 - blockFreq
5.2 - system settings
5.3.1 - FLM *5.3 - accessory settings
5.3.2 - shunt controlled add. heat *
5.3.3 - extra climate system *
5.3.4 - solar heating *
5.3.6 - step controlled add. heat
5.3.8 - hot water comfort *
5.3.11 - modbus *
5.3.12 - exhaust/supply air module *
5.3.15 - GBM communications module
*
5.3.16 - humidity sensor *
5.3.21 - external energy meter*
5.4 - soft in/outputs
5.5 - factory setting service
5.6 - forced control
5.7 - start guide
5.8 - quick start
5.9 - floor drying function
5.10 - change log
* Accessory needed.
Go to the main menu and hold the Back button in for 7
seconds to access the Service menu.
Sub-menus
Menu SERVICE has orange text and is intended for the
advanced user. This menu has several sub-menus. Status
information for the relevant menu can be found on the
display to the right of the menus.
operating settings Operating settings for the heat
pump.
system settings System settings for the heat pump, ac-
tivating accessories etc.
accessory settings Operational settings for different
accessories.
soft in/outputs Setting software controlled in and out-
puts on the input circuit board (AA3).
factory setting service Total reset of all settings (includ-
ing settings available to the user ) to default values.
forced control Forced control of the different compon-
ents in the heat pump.
43Chapter 8 | Control - MenusNIBE F1155
