Nibe F2040 Series User Manual

Technical specifications
IP 21
F2040-16F2040-12F2040-8F2040-6Air/water heat pump
Outdoor temp./
Supply temp.
Output data according to EN 14511 Δ T5K
2.80/0.23/12.102.75/0.31/9.002.68/0.41/6.602.57/0.56/4.60
-7/35 °C (floor)Heating
Capacity / Power input / COP (kW/kW/-)
at nominal flow
7.03/1.45/4.855.21/1.09/4.783.86/0.83/4.652.67/0.50/5.32
7/35 °C (floor)
9.33/2.38/3.926.91/1.79/3.865.11/1.36/3.762.32/0.55/4.20
2/35 °C (floor)
6.75/1.74/3.885.00/1.31/3.823.70/1.00/3.702.28/0.63/3.62
7/45 °C
9.18/2.98/3.086.80/2.24/3.045.03/1.70/2.961.93/0.67/2.88
2/45 °C
13.30/3.99/3.339.87/3.16/3.137.52/2.37/3.175.87/1.65/3.56
27/7 °CCooling
Capacity / Power input / EER (kW/kW/-)
at maximum flow
17.70/4.52/3.9111.70/3.32/3.5211.20/3.20/3.507.98/1.77/4.52
27/18 °C
13.04/4.53/2.889.45/3.41/2.777.10/2.65/2.684.86/1.86/2.61
35/7 °C
15.70/5.04/3.1211.20/3.58/3.129.19/2.98/3.087.03/2.03/3.45
35/18 °C
Electrical data
230V ~ 50Hz, 230V 2 ~ 50HzRated voltage
25231615A
rms
Max operating current, heat pump
24221514A
rms
Max operating current, compressor
5A
rms
Starting current
2 x 86868650WNominal output, fan
25251616A
rms
Fuse
1)
IP 24Enclosure class
Refrigerant circuit
R410AType of refrigerant
2,088GWP refrigerant
Twin RotaryType of compressor
M-MA68Compressor oil
4.02.92.551.5kgVolume
8.356.065.323.13tCO
2
equivalent
4.15 (41.5 bar)-MPaCut-out value pressostat HP
-4.15 (41.5 bar)Cut-out value HP
0.079 (0.79 bar)-MPaCut-out value pressostat LP
Brine
6,0004,3803,0002,530m
3
/hAirflow
-20 / 43°CMin. / Max. air temp.
Reverse cycleDefrosting system
Heating medium circuit
0.05/0.25 (0.5/4.5bar)MPaMin/Max system pressure heating medium
150805020lMin volume, climate system, heating/cooling
1501008050lMin volume, climate system, under floor cooling
0.790.570.380.29l/sMax flow, climate system
0.390.290.190.19l/sMin flow, climate system, at 100% circulation pump
speed (defrosting flow)
0.250.150.120.09l/sMin flow, heating
0.320.200.150.11l/sMin flow, cooling
25 / 58°CMin. / Max. HM temp continuous operation
G1"Connection heating medium ext thread
Dimensions and weight
114511451035993mmWidth
452452422364mmDepth
1450 (+50/-0)995 (+50/-0)895 (+50/-0)791 (+50/-0)mmHeight with stand
1351059066kgWeight (excl. packaging)
Miscellaneous
064 108064 092064 109064 206Part No.
1)
Specified output is limited with lower fusing.
65Chapter 12 | Technical dataNIBE F2040

Nibe F2040 Series Specifications

General

Series	F2040
Refrigerant	R410A
COP	Up to 5.0 (depending on model and operating conditions)
Sound Power Level Indoor Unit	N/A (Requires separate indoor unit)
Operating Temperature Range Cooling	+10°C to +43°C
Dimensions Indoor Unit (HxWxD)	N/A (Requires separate indoor unit)
Type	Air Source Heat Pump
