General
FIGHTER 410P
For Home Owners
2
In order to get the ultimate benefit from your heat pump FIGHTER 410P you should read
through the For Home Owners section in this Installation and Maintenance Instruction.
FIGHTER 410P is an exhaust air heat pump with preheated supply air . This means that it
collects the energy in the ventilation air and uses it for hot water and room heating.
A microprocessor ensures that the heat pump always works efficiently.
FIGHTER 410P is a Swedish-made quality product which will last a long time and run reli-
ably without unpleasant surprises.
For the installation engineer: Please, hand over to the home owner his manual after final-
ised installation.
To be filled in when the heat pump has been installed
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Rights to make any design or technical modifications are reserved.
Manufacter:
NIBE AB
Box 14
Järnvägsgatan 40
285 21 MARKARYD
SWEDEN
Maxiumum water
supply pressure
16 bar
Immersion heater R50 / 8000W /
230 V
Operating pressure, tap
water
6 bar
Expansion vessel, tap
water, charge pressure
3,5 bar
Expansion vessel,
heating water,
charge pressure
0,5 bar
Pressure reduction valve,
setting
3,5 bar
Volume, water heater 170 litres
Mass, unit, filled with
water
440 kg
Maximum primary
working
pressure (heating side)
2,5 bar
Set opening pressure of
temperature and
pressure valve
7 bar
Set opening pressure
relief valve
6 bar
Set opening, temerature
limiter,
immersion heater
88 °C
Set opening, temerature
limiter,
compressor
88 °C
Heating up time from
15 °C to stop
temperature for
compressor
5 h 41 min
Re-heating time, 70 % of
total volume (only
compressor working)
3 h 46 min
The serial number (103), should always be stated with all
correspondence with NIBE.
______________
Installation date
Installer
Chosen output, immersion heater
Circulation pump setting
Setting, trim valve
Fan rating
Switch Selected position on
terminal block (22)
for this cable (1 – 10)
Measured total
exhaust air flow
Position A (reduced)
Black cable 094
(supply air)
White cable 095
(exhaust air)
Supply air
Exhaust air
Position B (normal)
Black cable 096
(supply air)
White cable 097
(exhaust air)
Supply air
Exhaust air
Position C (forced)
Black cable 098
(supply air)
White cable 099
(exhaust air)
Supply air
Exhaust air
Setting damper (where applicable)
Setting Heating curve selection
Setting Offset heating curve
Date___________ Signed__________________________________
l/s
m
3
/h
