Nibe VVM 320 Technical Manual

Technical specifications
IP 21
3x400V
3x400V
F2030-7/F2030-9Compatible external parts
1)
F2040-8/F2040-12
9kWAdditional power
Electrical data
400V 3NAC 50 HzRated voltage
16AMax operating current
16AFuse
3 – 76WPower, GP1
3 – 45WPower, GP6
IP 21IP class
Heating medium circuit
low energyEnergy class, GP1
low energyEnergy class, GP6
0.25 (2.5 bar)MPaMax system pressure heating medium
400litres/hMin flow
70°CMax HM temp
Pipe connections
Ø22mmHeating medium
Ø22mmHot water connection
Ø22mmCold water connection
Ø22mmHeat pump connections
1)
Applies with an outdoor air heat pump at 7/45 °C (outdoor temperature/flow line temperature)
Miscellaneous
Indoor module
180lVolume, hot water heater
206lVolume, total indoor module
26lVolume buffer vessel
0.9 (9 bar)MPa (bar)Cut-off pressure, hot water heater
0.25 (2.5 bar)MPa (bar)Max permitted pressure in indoor module
Capacity hot water heating
According to EN 255-3
220lTap volume 40 °C at Eco- comfort
250lTap volume 40 °C at Normal comfort
280lTap volume 40 °C at Lux comfort
98WIdle loss according to DIN 4753-8.
Dimensions and weight
600mmWidth
615mmDepth
1800mmHeight (without base)
1830 – 1850mmHeight (with base)
1910mmRequired ceiling height
146kgWeight (excl. packaging and without water)
069 108Part number Copper - VVM 320 CU
622 40 86RSK No. Copper – VVM 320 CU
79Chapter 8 | Technical dataNIBE™ VVM 320

Nibe VVM 320 Specifications

General

Dimensions (HxWxD)	1800 x 600 x 615 mm
Power Supply	230 V
Frequency	50 Hz
Protection class	IP21
Compatible with	Nibe heat pumps
Display	Touch display
Smart Home Integration	Yes, via NIBE Uplink
Operating temperature	0°C to +45°C
Relative humidity	Max. 95 %
Type	Control unit for heat pumps
