9.1 - POST INSTALLATION
Install two 3” diameter posts parallel to the gate as
shown. Posts must be secured in the ground as
necessary for your type of soil conditions and building
codes. Post height must be a minimum of 24” out of
the ground.
DRIVEWAY
Direction of opening
Centerline of gate
6” 24”
Inside posts
5”
Mount operator to posts at desired height using the four
supplied 3” U-Bolts and tighten into place making sure
operator is level.
9.2 - CHASSIS MOUNTING
9 - 7251 INSTALLATION
