Nice M5BAR Instructions And Warnings For Installation And Use

28 – ENGLISH
ADDENDUM - PARAMETER LEGEND
Parameter Description
Radio channel 1
Activates the output when command 1 is sent with the transmitter, the command sent to the control unit is
ignored
Output active 24 V DC / max 10 W
Radio channel 2
Activates the output when command 2 is sent with the transmitter, the command sent to the control unit is
ignored
Output active 24 V DC / max 10 W
Radio channel 3
Activates the output when command 3 is sent with the transmitter, the command sent to the control unit is
ignored
Output active 24 V DC / max 10 W
Radio channel 4
Activates the output when command 4 is sent with the transmitter, the command sent to the control unit is
ignored
Output active 24 V DC / max 10 W
Suction cup
Activates when the boom is closed: at the start of an opening manoeuvre, the output deactivates and
opening starts after the “Suction cup time” has elapsed
Output active 24 V DC / max 10 W
Parameters of output OU4 (with accessory xba7)
24 V warning light
Light ashing during the manoeuvre (0.5 seconds on, 0.5 seconds off)
OGI
Light off: boom closed
Slow ashing: opening manoeuvre
Fast ashing: closing manoeuvre
Light on: boom open
Boom closed
Light on: boom closed
Light off: boom in other positions
Boom open
Light on: boom open
Light off: boom in other positions
Courtesy light
Light lit for the entire duration of the manoeuvre; after the manoeuvre, it remains lit for a duration
corresponding to the courtesy light time
Parameters of output OU4 (with accessory xba8)
Red trafc light
Slow ashing: closing manoeuvre
Steady red light: boom closed
Light off: application in other positions
Green trafc light
Slow ashing: opening manoeuvre
Steady green light: boom open
Light off: application in other positions
One-way trafc light
Green light: boom open
Red light: all other cases
Alternate one-way trafc
light
For the system to operate in this mode, the commands must be sent to the control unit as follows:
Commands for inside: Input 2 or Loop 1 congured as open
Commands for outside: Input 3 or Loop 2 congured as open
Operation:
an open command sent from inside activates the green light inside and the red light outside, giving priority
to the person inside
an open command sent from outside activates the green light outside and the red light inside, giving
priority to the person outside
When the boom is closed or closing, the light is red on both sides
Pedestrian trafc light
Boom closed: green light inside, red light outside
Boom open: red light inside, green light outside
Boom in other positions: red light inside and outside
